KINKI STUDIO - EX-P7

Kinki Studio preamp EXP7

More details

2 190,00 € tax incl.

Add to wishlist





The EX Series is tuned to reproduce sound quality with balance mid and smooth extension in both ends, high and low extension.

True Class-A biased, fully discrete input and output stages are the heart of the EX-P7. Rich in tonal quality, details, and high resolution.

Silky smooth volume control thanks to the discrete R2R volume control, of which known for its precise and accurate volume adjustment with precision matched resistors.

the entire chassis is made of 8-10mm thick of anodized aluminum block, effectively eliminate the nasty EMI/EMC induced from the surrounding equipment.

Parameters

  • Frequency Response: 0-150kHz (±1dB)
  • THDN: 0.003% (-80dB)
  • S/N Ratio: >90dB
  • Channel Seperation: >90dB

Input / Output

  • Input Sensitivity: 2.25Vrms - 3.6Vrms
  • Input Impedance: 50kΩ
  • Input Connector: RCA x 2, XLR x 1

  • Output Voltage: 2.25Vrms - 3.6Vrms
  • Output Impedance: 75Ω
  • Output Connector: RCA x 2, XLR x 1

Dimension & Weight

  • Dimension: 430W x 125H x 370D
  • Weight: 13KG
